ZDE9S Socket, D, T&D, 9WAY ITT Cannon

ITT CANNONSKU: ZDE9S Order code: 1348016

Price:
Sale price€8,08

Tax included Shipping calculated at checkout

Stock:
In stock (5343 units), ready to be shipped

Documents et téléchargements

Description

ITT CANNON - ZDE9S - D Sub Connector, DB9, Standard, Receptacle, ZDE, 9 Contacts, DE, Solder Cup

  • No. of Contacts: 9Contacts
  • Gender: Receptacle
  • Contact Termination Type: Solder Cup
  • D Sub Shell Size: DE
  • Product Range: ZDE Series
  • Connector Body Material: Steel Body
  • Contact Material: Copper Alloy
  • Contact Plating: Gold over Nickel Plated Contacts
  • Body Plating: Tin
  • Case Material: Steel, tin plating
  • Connector Mounting: Cable Mount, Panel Mount
  • Contact Resistance: 20mohm
  • Contact Termination: Solder
  • Current Temperature: 60°C
  • D Sub Connector Type: Standard
  • DC Current Max: 5A
  • Flammability Rating: UL94V-0
  • Material: Steel
  • No. of Mating Cycles: 50
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -55°C
  • Termination Method: Solder Bucket
  • Withstand Voltage: 1000V
  • Working Voltage: 500V
