ZDAA26P Connector, Solder Cup, Plug, 26 Way ITT Cannon

ITT CANNONSKU: ZDAA26P Order code: 1760274

Price:
Sale price€15,29

Tax included Shipping calculated at checkout

Stock:
In stock (1916 units), ready to be shipped

Documents et téléchargements

Description

ITT CANNON - ZDAA26P - D Sub Connector, HD26, High Density, Plug, ZDA, 26 Contacts, DA, Solder Cup

  • No. of Contacts: 26Contacts
  • Gender: Plug
  • Contact Termination Type: Solder Cup
  • D Sub Shell Size: DA
  • Product Range: ZDA Series
  • Connector Body Material: Steel Body
  • Contact Material: -
  • Contact Plating: -
  • Connector Mounting: Cable Mount
  • Contact Resistance: 20mohm
  • Contact Termination: Solder
  • Current Rating: 2A
  • D Sub Connector Type: High Density
  • Flammability Rating: UL94V-0
  • Insulation Resistance: 5000Mohm
  • Material: Steel
  • No. of Mating Cycles: 50
  • Operating Temperature Max: 105°C
  • Operating Temperature Min: -55°C
  • Withstand Voltage: 1000V
