TXS2-4.5V Relay, Signal, DPDT, 30Vdc, 1A Panasonic

PANASONICSKU: TXS2-4.5V Order code: 1608335

Price:
Sale price€5,51

Tax included Shipping calculated at checkout

Stock:
In stock (572 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - TXS2-4.5V - Signal Relay, 4.5 VDC, DPDT, 1 A, TX, Through Hole, Non Latching

  • Coil Voltage: 4.5VDC
  • Contact Configuration: DPDT
  • Contact Current: 1A
  • Product Range: TX-S Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: -
  • Contact Voltage VDC: 30V
  • Contact Material: Silver
  • Coil Resistance: 405ohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approvals & Standards: CSA, UL
  • Coil Current: 11.1mA
  • Coil Power Continuous: 50mW
  • Coil Voltage VDC Nom: 4.5V
  • Contact Current DC Max: 1A
  • Contact Current Max: 1A
  • Contact Voltage DC Max: 110V
  • Contact Voltage DC Nom: 30V
  • External Depth: 15mm
  • External Height: 8.2mm
  • External Length / Height: 8.2mm
  • External Width: 7.4mm
  • Nom Operating Power: 50mW
  • Relay Type: General Purpose
