SCHMERSAL - TVS 410SK-11/11U - Limit Switch, 2NC / 2NO, 4 A, 230 V
- Limit Switch Actuator: -
- Contact Configuration: 2NC / 2NO
- Contact Current AC Max: 4A
- Contact Voltage AC Max: 230V
- Operating Force Max: -
- Product Range: -
- Contact Current DC Max: 1A
- Contact Voltage DC Max: 24V
- Actuator Type: Adjustable Switching Angle
- Approval Bodies: BG
- Approval Category: UL Recognised
- Case Material: Metal
- External Depth: 21.5mm
- External Length / Height: 115mm
- External Width: 141mm
- IP / NEMA Rating: IP65
- Operating Temperature Max: 65°C
- Operating Temperature Min: -25°C
- Thermal Current Rating: 2.5A
