TQ2-24V Relay, Signal, DPDT, 30Vdc, 1A Panasonic

PANASONICSKU: TQ2-24V Order code: 1175717

Price:
Sale price€7,65

Tax included Shipping calculated at checkout

Stock:
In stock (3705 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - TQ2-24V - Signal Relay, 24 VDC, DPDT, 1 A, TQ, Through Hole, Non Latching

  • Coil Voltage: 24VDC
  • Contact Configuration: DPDT
  • Contact Current: 1A
  • Product Range: TQ Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Relay Terminals: Solder
  • Contact Voltage VAC: 125V
  • Contact Voltage VDC: 30V
  • Contact Material: Gold
  • Coil Resistance: 2.88kohm
  • SVHC: No SVHC (07-Jul-2017)
  • Approvals & Standards: CSA, UL
  • Coil Current: 8.3mA
  • Coil Power Continuous: 200mW
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 1A
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 30V
  • External Depth: 14mm
  • External Height: 5mm
  • External Width: 9mm
