TRACO POWER - TMH 1205D - Isolated Through Hole DC/DC Converter, ITE, 1:1, 2 W, 2 Output, 5 V, 200 mA
- No. of Outputs: 2 Output
- Output Power Max: 2W
- Output Voltage - Output 1: 5V
- Output Current - Output 1: 200mA
- Output Voltage - Output 2: -5V
- Output Current - Output 2: 200mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 10.8V
- Input Voltage DC Max: 13.2V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 7.5mm
- Height: 10.2mm
- Depth: 19.5mm
- SVHC: No SVHC (27-Jun-2018)
- Efficiency: 79%
- Input Voltage: 12VDC
- Isolation Voltage: 1kV
- No. of Outputs: 2Outputs
- Output Current - Max: 200mA
- Output Ripple Voltage pk-pk: 150mV
- Output Voltage +: 5VDC
- Output Voltage -: 5VDC
- Power Rating: 2W
- Supply Voltage: 12V
