TRACO POWER - TEN 8-4823 - Isolated Through Hole DC/DC Converter, ITE, 2:1, 8 W, 2 Output, 15 V, 265 mA
- No. of Outputs: 2 Output
- Output Power Max: 8W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 265mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 265mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: -
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 75V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 20.3mm
- Height: 10.2mm
- Depth: 32mm
- SVHC: No SVHC (27-Jun-2018)
- No. of Outputs: 2Outputs
