Description
TRACO POWER - TEN 40-2410N - Isolated Through Hole DC/DC Converter, ITE, 2:1, 40 W, 1 Output, 3.3 V, 8 A
- No. of Outputs: 1 Output
- Output Power Max: 40W
- Output Voltage - Output 1: 3.3V
- Output Current - Output 1: 8A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: TEN 40N Series
- Input Voltage DC Min: 18V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed, Adjustable
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.2mm
- Depth: 50.8mm
- SVHC: No SVHC (27-Jun-2018)
- Approvals & Standards: CSA, IEC, UL
