T000315 LED Indicator, Panel Mnt, 8mm, Green CML Innovative Technologies

CML INNOVATIVE TECHNOLOGIESSKU: T000315 Order code: 2472234

Price:
Sale price€4,50

Tax included Shipping calculated at checkout

Stock:
In stock (1711 units), ready to be shipped

Documents et téléchargements

Description

CML INNOVATIVE TECHNOLOGIES - T000315 - LED Panel Mount Indicator, Snap-in, Green, 24 VDC, 8 mm, Not Rated

  • LED Colour: Green
  • Operating Voltage: 24VDC
  • Mounting Hole Dia: 8mm
  • Forward Current If: -
  • Luminous Intensity: -
  • IP / NEMA Rating: Not Rated
  • Product Range: -
  • SVHC: No SVHC (15-Jan-2018)
  • Bezel Diameter: 9.5mm
  • Bulb Size: 5mm
  • External Diameter: 9.5mm
  • Fixing Hole Diameter: 8mm
  • Forward Current If Max: 10mA
  • Forward Voltage: 24V
  • Forward Voltage VF Max: 24V
  • LED / Lamp Size: 5mm
  • Lead Length: 450mm
  • Length Behind Bezel: 10mm
  • Lens Shape: Dome
  • Luminous Intensity Typ: 25mcd
  • Material: Black Plastic Bezel
  • Operating Temperature Max: 50°C
  • Operating Temperature Min: -20°C
  • Operating Temperature Range: -20°C to +50°C
  • Panel Thickness Max: 3mm
  • Peak Wavelength: 565nm
  • Supply Voltage V DC: 24V
  • Voltage Rating V DC: 24V
  • Voltage Vf Typ: 24VDC
  • Wavelength Typ: 565nm
