STMICROELECTRONICS - STTH12R06FP - Fast / Ultrafast Diode, 600 V, 12 A, Single, 2.9 V, 25 ns, 100 A
- Repetitive Reverse Voltage Vrrm Max: 600V
- Forward Current If(AV): 12A
- Diode Configuration: Single
- Forward Voltage VF Max: 2.9V
- Reverse Recovery Time trr Max: 25ns
- Forward Surge Current Ifsm Max: 100A
- Operating Temperature Max: 175°C
- Diode Case Style: TO-220FPAC
- No. of Pins: 2 Pin
- Product Range: STTH1 Series
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Case Temperature Tc @ If: 50°C
- Current If @ Vf: 12A
- Current Ifsm: 100A
- Current Ir Max: 45µA
- Current Temperature: 50°C
- Diode Type: Fast Recovery
- Forward Voltage: 2.9V
- Junction Temperature Tj Max: 175°C
- No. of Pins: 2Pins
- Operating Temperature Min: -65°C
- Operating Temperature Range: -65°C to +175°C
- Pin Configuration: K,A
