ST2-DC12V-F Relay, DPST-NO, 250VAC, 30Vdc, 8A Panasonic

PANASONICSKU: ST2-DC12V-F Order code: 2103598

Price:
Sale price€17,12

Tax included Shipping calculated at checkout

Stock:
In stock (154 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - ST2-DC12V-F - General Purpose Relay, ST Series, Power, Non Latching, DPST-NO, 12 VDC, 8 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 12VDC
  • Contact Current: 8A
  • Product Range: ST Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 600ohm
  • SVHC: No SVHC (07-Jul-2017)
  • Coil Current: 20mA
  • Coil Voltage VDC Nom: 12V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 380V
  • Contact Voltage DC Nom: 250V
  • External Depth: 31mm
  • External Height: 11.3mm
  • External Width: 14mm
  • Nom Operating Power: 240mW
  • Relay Type: Power - General Purpose
