Description
MULTICOMP PRO - SS310+ - Schottky Rectifier, 100 V, 3 A, Single, DO-214AB (SMC), 2 Pins, 850 mV
- Repetitive Reverse Voltage Vrrm Max: 100V
- Forward Current If(AV): 3A
- Diode Configuration: Single
- Diode Case Style: DO-214AB
- No. of Pins: 2Pins
- Forward Voltage VF Max: 850mV
- Forward Surge Current Ifsm Max: 80A
- Operating Temperature Max: 150°C
- Product Range: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Alternate Case Style: DO-214AB
- Current Ifsm: 100A
- Current Ir Max: 600µA
- Diode Type: Schottky
- Forward Voltage: 850mV
- Junction Temperature Tj Max: 150°C
- Junction Temperature Tj Min: -55°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +150°C
- Reverse Voltage Vr Max: 100V
- Semiconductor Technology: Si
- Termination Type: Surface Mount Device
