BOURNS - SRR1280-820M - Power Inductor (SMD), 82 µH, 2.3 A, Shielded, 2.2 A, SRR1280
- Inductance: 82µH
- RMS Current (Irms): 2.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 2.2A
- Product Range: SRR1280 Series
- Power Inductor Case: 12.5mm x 12.5mm x 7.5mm
- DC Resistance Max: 0.13ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- No. of Pins: 2Pins
- Q Factor: 20
- Q Test Frequency: 796kHz
- Self Resonant Frequency Min: 5MHz
