BOURNS - SRR0745A-391M - Power Inductor (SMD), 390 µH, 320 mA, Shielded, 360 mA, SRR0745A
- Inductance: 390µH
- RMS Current (Irms): 320mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 360mA
- Product Range: SRR0745A Series
- Power Inductor Case: 7.3mm x 7.3mm x 4.5mm
- DC Resistance Max: 1.85ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- Automotive Qualification Standard: AEC-Q200
