BOURNS - SRP7028A-1R8M - Power Inductor (SMD), 1.8 µH, 8.5 A, Shielded, 16 A, SRP7028A, 7.3mm x 6.6mm x 2.8mm
- Inductance: 1.8µH
- RMS Current (Irms): 8.5A
- Inductor Construction: Shielded
- Saturation Current (Isat): 16A
- Product Range: SRP7028A Series
- Power Inductor Case: 7.3mm x 6.6mm x 2.8mm
- DC Resistance Max: 0.017ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2018)
- Automotive Qualification Standard: AEC-Q200
