CELDUC - SO445420 - Solid State Relay, SPST-NO, 4mA to 20mA, AC, 12 mOhm
- On State Current Max: -
 - Supply Voltage Min: -
 - Supply Voltage Max: -
 - Isolation Voltage: 4kV
 - Supply Frequency: 60Hz
 - Operating Temperature Min: -40°C
 - Operating Temperature Max: 100°C
 - Product Range: -
 - SVHC: No SVHC (07-Jul-2017)
 - Control Current Max: 20mA
 - Control Current Min: 4mA
 - Control Voltage DC Min: 10V
 - Control Voltage Type: DC
 - Input Voltage Max: 265V
 - Input Voltage Min: 90V
 - Load Current: 50A
 - Load Current Min: 35mA
 - Load Current RMS Max: 50A
 - Operating Frequency Max: 70Hz
 - Operating Frequency Min: 40Hz
 - Operating Temperature Range: -40°C to +100°C
 - Operating Voltage Range: 90Vrms to 280Vrms
 - Output Type: Thyristor
 - Output Voltage Max: 265V
 - Output Voltage Min: 90V
 - Peak Load Voltage +: 600V
 - RMS Load Current Min: 5mA
 - RMS Load Voltage Max: 900V
 - RMS Load Voltage Min: 600V
 - Surge Current: 720A
