Description
POTTER&BRUMFIELD - TE CONNECTIVITY - 1-1419108-7 - Power Relay, DPDT, 24 VDC, 8 A, RT2, Through Hole, Non Latching
- Contact Configuration: DPDT
- Coil Voltage: 24VDC
- Contact Current: 8A
- Product Range: RT2 Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 1.44kohm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: CSA, UL, VDE
- Coil Current: 16.7mA
- Coil Voltage VDC Nom: 24V
- Contact Current AC Max: 8A
- Contact Current Max: 8A
- Contact Voltage AC Max: 400V
- Contact Voltage AC Nom: 277V
- Contact Voltage DC Nom: 30V
- External Depth: 15.7mm
- External Height: 29mm
- External Length / Height: 29mm
- External Width: 12.7mm
- Nom Operating Power: 400mW
- Relay Type: Power - General Purpose
