Description
TE CONNECTIVITY - 1415900-2 - General Purpose Relay, Power PCB Relay RT1 Series, Power, Non Latching, SPST, 12 VDC, 16 A
- Contact Configuration: SPST
- Coil Voltage: 12VDC
- Contact Current: 16A
- Product Range: RT1 Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 360ohm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: CSA, UL, VDE
- Coil Voltage VDC Nom: 12V
- Contact Current DC Max: 16A
- Contact Current Max: 16A
- Contact Voltage AC Max: 400V
- Contact Voltage AC Nom: 250V
- External Depth: 12.7mm
- External Height: 16mm
- External Length / Height: 16mm
- External Width: 29mm
- Nom Operating Power: 400mW
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Relay Type: Power
