XP POWER - RDC3072S15 - Isolated Through Hole DC/DC Converter, Railway, 4:1, 30 W, 1 Output, 15 V, 2 A
- No. of Outputs: 1 Output
- Output Power Max: 30W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 2A
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: RDC Series
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 140V
- DC / DC Converter Output Type: Adjustable
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.16mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- No. of Outputs: 1Outputs
