Description
- No. of Outputs: 2 Output
- Output Power Max: 20W
- Output Voltage - Output 1: 15V
- Output Current - Output 1: 670mA
- Output Voltage - Output 2: -15V
- Output Current - Output 2: 670mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: RDC Series
- Input Voltage DC Min: 36V
- Input Voltage DC Max: 140V
- DC / DC Converter Output Type: Adjustable
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 25.4mm
- Height: 10.16mm
- Depth: 50.8mm
- SVHC: No SVHC (15-Jan-2018)
- No. of Outputs: 2Outputs
