QSH5718-76-28-189 Stepper Motor, 57mm, 2.8A, 1.89NM Trinamic / Analog Devices

TRINAMIC / ANALOG DEVICESSKU: QSH5718-76-28-189 Order code: 1907703

Price:
Sale price€189,79

Tax included Shipping calculated at checkout

Stock:
In stock (6 units), ready to be shipped

Documents et téléchargements

Description

TRINAMIC / ANALOG DEVICES - QSH5718-76-28-189 - Stepper Motor, Single Shaft, Hybrid, 56.4 mm, DC, 1.8 °, 1.89 N-m

  • Coil Type: DC
  • Torque Max: 1.89N-m
  • Current Rating: -
  • No. of Phases: Two Phase
  • Resistance: 1.13ohm
  • Inductance: 3.6mH
  • Inertia: 480g-cm²
  • Product Range: -
  • SVHC: No SVHC (27-Jun-2018)
  • Current per Phase: 2.8A
  • Detent Torque: 6.6N-cm
  • External Length / Height: 41mm
  • Flange Width: 56.4mm
  • Holding Torque: 189N-cm
  • No. of Shafts: 1
  • Phase Resistance: 1.13ohm
