QK040K7TP Triac, ALTERNISTOR, 1kV, 40A, TO-218AC-3 LITTELFUSE

LITTELFUSESKU: QK040K7TP Order code: 2777207

Price:
Sale price€18,43

Tax included Shipping calculated at checkout

Stock:
In stock (132 units), ready to be shipped

Documents et téléchargements

Description

LITTELFUSE - QK040K7TP - Triac, Teccor®, 1 kV, 40 A, TO-218AC, 2 V, 335 A, 100 mA

  • Peak Repetitive Off-State Voltage, Vdrm: 1kV
  • On State RMS Current IT(rms): 40A
  • Triac Case Style: TO-218AC
  • Gate Trigger Current Max (QI), Igt: 100mA
  • Gate Trigger Voltage Max Vgt: 2V
  • Peak Gate Power: -
  • Peak Non Rep Surge Current Itsm 50Hz: 335A
  • Holding Current Max Ih: 100mA
  • No. of Pins: 3Pins
  • Operating Temperature Max: 125°C
  • Product Range: Qxx40xx Series
  • MSL: MSL 1 - Unlimited
  • SVHC: No SVHC (07-Jul-2017)
