OVLAW4CB7 LED, 3mm, 45DEG, White TT Electronics / OPTEK Technology

TT ELECTRONICS / OPTEK TECHNOLOGYSKU: OVLAW4CB7 Order code: 1497991

Price:
Sale price€0,89

Tax included Shipping calculated at checkout

Stock:
In stock (14371 units), ready to be shipped

Documents et téléchargements

Description

TT ELECTRONICS / OPTEK TECHNOLOGY - OVLAW4CB7 - LED, White, Through Hole, T-1 (3mm), 20 mA, 3.4 V, 6200 mcd

  • LED Colour: White
  • LED Mounting: Through Hole
  • Bulb Size: T-1 (3mm)
  • Forward Current If: 20mA
  • Forward Voltage: 3.4V
  • Luminous Intensity: 6200mcd
  • Viewing Angle: 45°
  • Lens Shape: Round
  • Product Range: -
  • Automotive Qualification Standard: -
  • MSL: -
  • SVHC: No SVHC (27-Jun-2018)
  • LED / Lamp Size: 3mm / T-1
  • Lens Diameter: 3mm
  • Material: InGaN
  • Operating Temperature Max: 95°C
  • Operating Temperature Min: -40°C
  • Operating Temperature Range: -40°C to +95°C
  • PIV Max: 5V
  • Reverse Leakage Current Max: 10µA
  • Storage Temperature Max: +100°C
  • Storage Temperature Min: -40°C
  • Voltage Vf Typ: 3.4V
