Description
TT ELECTRONICS / OPTEK TECHNOLOGY - OPB742 - Reflective Photo Interrupter, OPB742 Series, Phototransistor, Through Hole, 3.81 mm, 40 mA, 2 Vr
- Sensor Output: Phototransistor
- Sensor Mounting: Through Hole
- Sensing Distance: 3.81mm
- Forward Current If: 40mA
- Reverse Voltage Vr: 2V
- Collector Emitter Voltage V(br)ceo: 30V
- Forward Voltage: 1.8V
- Product Range: OPB740 Series
- SVHC: No SVHC (27-Jun-2018)
- Current Ic Min: 10µA
- Detecting Distance: 3.81
- External Length / Height: 15.29mm
- Forward Voltage VF Max: 1.7V
- Input Current: 40mA
- No. of Channels: 1Channels
- No. of Pins: 4Pins
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +85°C
- Optocoupler Output Type: Phototransistor
- Output Voltage: 30V
- Peak Wavelength: 880nm
- Reverse Leakage Current Max: 100µA
- Voltage BVceo Min: 30V
- Voltage BVeco Min: 5V
