MSS1278-683MLD Inductor, 68UH, 2.6a, 20%, Pwr, 6.5MHz COILCRAFT

COILCRAFTSKU: MSS1278-683MLD Order code: 2288510

Price:
Sale price€5,88

Tax included Shipping calculated at checkout

Stock:
In stock (659 units), ready to be shipped

Documents et téléchargements

Description

COILCRAFT - MSS1278-683MLD - Power Inductor (SMD), 68 µH, 2.6 A, Shielded, 3.4 A, MSS1278

  • Inductance: 68µH
  • RMS Current (Irms): 2.6A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 3.4A
  • Product Range: MSS1278 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
  • DC Resistance Max: 0.1015ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 6.5MHz
