MSS1278-562MLD Inductor, 5.6uH, 6.2A, 20%, Pwr, 24MHz COILCRAFT

COILCRAFTSKU: MSS1278-562MLD Order code: 2288495

Price:
Sale price€5,68

Tax included Shipping calculated at checkout

Stock:
In stock (28 units), ready to be shipped

Documenten en downloads

Description

COILCRAFT - MSS1278-562MLD - Power Inductor (SMD), 5.6 µH, 6.2 A, Shielded, 12.2 A, MSS1278

  • Inductance: 5.6µH
  • RMS Current (Irms): 6.2A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 12.2A
  • Product Range: MSS1278 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
  • DC Resistance Max: 0.0175ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 24MHz
