MSS1278-223MLD Inductor, 22UH, 4A, 20%, Pwr, 11MHZ COILCRAFT

COILCRAFTSKU: MSS1278-223MLD Order code: 2288504

Price:
Sale price€5,83

Tax included Shipping calculated at checkout

Stock:
In stock (1362 units), ready to be shipped

Documents et téléchargements

Description

COILCRAFT - MSS1278-223MLD - Power Inductor (SMD), 22 µH, 4 A, Shielded, 6.04 A, MSS1278

  • Inductance: 22µH
  • RMS Current (Irms): 4A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 6.04A
  • Product Range: MSS1278 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
  • DC Resistance Max: 0.0395ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 11MHz
