MSS1278-104MLD Inductor, 100UH,2.2A,20%,4.5MHz, Reel COILCRAFT

COILCRAFTSKU: MSS1278-104MLD Order code: 2297584

Price:
Sale price€3,13

Tax included Shipping calculated at checkout

Stock:
In stock (1000 units), ready to be shipped

Documents et téléchargements

Description

COILCRAFT - MSS1278-104MLD - Power Inductor (SMD), 100 µH, 2.2 A, Shielded, 2.88 A, MSS1278, 12.3mm x 12.3mm x 8.05mm

  • Inductance: 100µH
  • RMS Current (Irms): 2.2A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 2.88A
  • Product Range: MSS1278 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 8.05mm
  • DC Resistance Max: 0.1502ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Reel Quantity: 500
  • Self Resonant Frequency Min: 4.5MHz
