MSS1260T-683MLD Inductor, 68UH, 2.3a, 20%, Pwr, 10MHz COILCRAFT

COILCRAFTSKU: MSS1260T-683MLD Order code: 2288472

Price:
Sale price€6,68

Tax included Shipping calculated at checkout

Stock:
In stock (500 units), ready to be shipped

Documenten en downloads

Description

COILCRAFT - MSS1260T-683MLD - Power Inductor (SMD), 68 µH, 2.3 A, Shielded, 2.46 A, MSS1260T

  • Inductance: 68µH
  • RMS Current (Irms): 2.3A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 2.46A
  • Product Range: MSS1260T Series
  • Power Inductor Case: 12.3mm x 12.3mm x 6mm
  • DC Resistance Max: 0.105ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 10MHz
