MSS1260-682MLD Inductor, 6.8UH, 5.9A, 20%, Pwr, 27MHz COILCRAFT

COILCRAFTSKU: MSS1260-682MLD Order code: 2288422

Price:
Sale price€5,74

Tax included Shipping calculated at checkout

Stock:
In stock (133 units), ready to be shipped

Documenten en downloads

Description

COILCRAFT - MSS1260-682MLD - Power Inductor (SMD), 6.8 µH, 5.9 A, Shielded, 7.4 A, MSS1260

  • Inductance: 6.8µH
  • RMS Current (Irms): 5.9A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 7.4A
  • Product Range: MSS1260 Series
  • Power Inductor Case: 12.3mm x 12.3mm x 6mm
  • DC Resistance Max: 0.0185ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 27MHz
