Description
COILCRAFT - MSS1246T-223MLC - Power Inductor (SMD), 22 µH, 3.14 A, Shielded, 3.84 A, MSS1246T
- Inductance: 22µH
- RMS Current (Irms): 3.14A
- Inductor Construction: Shielded
- Saturation Current (Isat): 3.84A
- Product Range: MSS1246T Series
- Power Inductor Case: 12mm x 12mm x 4.6mm
- DC Resistance Max: 0.067ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 18MHz
