Description
COILCRAFT - MSS1246-394KLC - Power Inductor (SMD), 390 µH, 790 mA, Shielded, 910 mA, MSS1246
- Inductance: 390µH
- RMS Current (Irms): 790mA
- Inductor Construction: Shielded
- Saturation Current (Isat): 910mA
- Product Range: MSS1246 Series
- Power Inductor Case: 12mm x 12mm x 4.6mm
- DC Resistance Max: 0.9042ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 3.8MHz
