Description
COILCRAFT - MSS1246-154KLC - Power Inductor (SMD), 150 µH, 1.3 A, Shielded, 1.36 A, MSS1246, 12mm x 12mm x 4.6mm
- Inductance: 150µH
- RMS Current (Irms): 1.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.36A
- Product Range: MSS1246 Series
- Power Inductor Case: 12mm x 12mm x 4.6mm
- DC Resistance Max: 0.363ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Self Resonant Frequency Min: 6.6MHz
