MSS1048-333MLC Inductor, 33UH, 2.8A, 20%, Pwr, 11MHZ COILCRAFT

COILCRAFTSKU: MSS1048-333MLC Order code: 2288270

Price:
Sale price€5,58

Tax included Shipping calculated at checkout

Stock:
In stock (246 units), ready to be shipped

Documents et téléchargements

Description

COILCRAFT - MSS1048-333MLC - Power Inductor (SMD), 33 µH, 2.8 A, Shielded, 1.66 A, MSS1048, 10.2mm x 10mm x 4.8mm

  • Inductance: 33µH
  • RMS Current (Irms): 2.8A
  • Inductor Construction: Shielded
  • Saturation Current (Isat): 1.66A
  • Product Range: MSS1048 Series
  • Power Inductor Case: 10.2mm x 10mm x 4.8mm
  • DC Resistance Max: 0.068ohm
  • Inductance Tolerance: ± 20%
  • SVHC: No SVHC (15-Jan-2019)
  • Automotive Qualification Standard: AEC-Q200
  • Self Resonant Frequency Min: 11MHz
