Description
COILCRAFT - MSS1038-333MLC - Power Inductor (SMD), 33 µH, 2.3 A, Shielded, 1.84 A, MSS1038, 10.2mm x 10mm x 3.8mm
- Inductance: 33µH
- RMS Current (Irms): 2.3A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.84A
- Product Range: MSS1038 Series
- Power Inductor Case: 10.2mm x 10mm x 3.8mm
- DC Resistance Max: 0.093ohm
- Inductance Tolerance: ± 20%
- SVHC: No SVHC (15-Jan-2019)
- Automotive Qualification Standard: AEC-Q200
- Reel Quantity: 250
- Self Resonant Frequency Min: 13MHz
