mF-RX065/72-0 MULTIFUSE, Radial, 0.65A, 72V Bourns

BOURNSSKU: MF-RX065/72-0 Order code: 1652190

Price:
Sale price€0,93

Tax included Shipping calculated at checkout

Stock:
In stock (663 units), ready to be shipped

Documents et téléchargements

Description

BOURNS - MF-RX065/72-0 - Resettable Fuse, PPTC, MF-RX/72, 72 VDC, 650 mA, 1.3 A, 5.3 s, Round

  • Thermistor Mounting: Through Hole
  • Product Range: MF-RX/72 Series
  • Holding Current: 650mA
  • Tripping Current: 1.3A
  • Voltage Rating: 72V
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 85°C
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2018)
  • Approval Category: UL Recognised
  • Body Diameter: 9.7mm
  • Carrying Current Max: 40A
  • Case Material: Epoxy polymer
  • Current Max: 40A
  • External Depth: 3.1mm
  • External Length / Height: 15.2mm
  • External Width: 9.7mm
  • Flammability Rating: UL94V-0
  • Height: 15.2mm
  • Holding Current Max Ih: 0.65A
  • Initial Resistance Max: 0.48ohm
  • Initial Resistance Min: 0.27ohm
  • Lead Diameter: 0.51mm
  • Lead Length: 7.6mm
  • Lead Spacing: 5.1mm
  • Operating Voltage: 72V
  • PTC Fuse Case Style: Radial Leaded
  • Resistance Temperature: 23°C
  • Surface Tripped Temperature Max: 125°C
  • Termination Type: Radial Leaded
  • Thermistor Type: PTC Resettable Fuse
