Description
BOURNS - MF-RX050/72-0 - Resettable Fuse, PPTC, MF-RX/72, 72 VDC, 500 mA, 1 A, 4 s, Round
- Thermistor Mounting: Through Hole
- Product Range: MF-RX/72 Series
- Holding Current: 500mA
- Tripping Current: 1A
- Voltage Rating: 72V
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Category: UL Recognised
- Body Diameter: 7.9mm
- Case Material: Epoxy polymer
- Current Max: 40A
- External Depth: 3.1mm
- External Length / Height: 13.7mm
- External Width: 7.9mm
- Flammability Rating: UL94V-0
- Height: 13.7mm
- Holding Current Max Ih: 0.5A
- Initial Resistance Max: 0.77ohm
- Initial Resistance Min: 0.41ohm
- Lead Diameter: 0.51mm
- Lead Length: 7.6mm
- Lead Spacing: 5.1mm
- Operating Voltage: 72V
- PTC Fuse Case Style: Radial Leaded
- Resistance Temperature: 23°C
- Surface Tripped Temperature Max: 125°C
- Termination Type: Radial Leaded
- Thermistor Type: PTC Resettable Fuse
