Description
BOURNS - MF-R250 - Resettable Fuse, PPTC, MF-R, 30 VDC, 2.5 A, 5 A, 10.3 s, Rectangular
- Thermistor Mounting: Through Hole
- Product Range: MF-R Series
- Holding Current: 2.5A
- Tripping Current: 5A
- Voltage Rating: 30V
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Body Diameter: 12mm
- Carrying Current Max: 40A
- Case Material: Epoxy polymer
- Current Max: 40A
- External Depth: 3mm
- External Length / Height: 18.3mm
- External Width: 12mm
- Flammability Rating: UL94V-0
- Holding Current Max Ih: 2.5A
- Initial Resistance Max: 0.048ohm
- Initial Resistance Min: 0.025ohm
- Lead Diameter: 0.81mm
- Lead Length: 7.6mm
- Lead Spacing: 5.1mm
- Operating Voltage: 30V
- PTC Fuse Case Style: Radial Leaded
- Pitch Max: 5.8mm
- Pitch Min: 4.3mm
- Surface Tripped Temperature Max: 125°C
- Thermistor Type: PTC Resettable Fuse
