Description
BOURNS - MF-R185 - Resettable Fuse, PPTC, MF-R, 30 VDC, 1.85 A, 3.7 A, 8.7 s, Round
- Thermistor Mounting: Through Hole
- Product Range: MF-R Series
- Holding Current: 1.85A
- Tripping Current: 3.7A
- Voltage Rating: 30V
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Approval Bodies: CSA, TUV, UL
- Body Diameter: 10.2mm
- Carrying Current Max: 40A
- Case Material: Epoxy polymer
- Current Max: 40A
- External Depth: 3mm
- External Length / Height: 15.7mm
- External Width: 12mm
- Flammability Rating: UL94V-0
- Holding Current Max Ih: 1.85A
- Initial Resistance Max: 0.07ohm
- Initial Resistance Min: 0.04ohm
- Lead Diameter: 0.51mm
- Lead Length: 7.6mm
- Lead Spacing: 5.1mm
- Operating Voltage: 30V
- PTC Fuse Case Style: Radial Leaded
- Pitch Max: 5.8mm
- Pitch Min: 4.3mm
- Surface Tripped Temperature Max: 125°C
- Thermistor Type: PTC Resettable Fuse
