Description
MULTICOMP PRO - MCSD75-560KU - Power Inductor (SMD), 56 µH, 940 mA, Unshielded, MCSD75, 7.8mm x 7mm x 5mm
- Inductance: 56µH
- RMS Current (Irms): 940mA
- Inductor Construction: Unshielded
- Saturation Current (Isat): -
- Product Range: MCSD75 Series
- Power Inductor Case: 7.8mm x 7mm x 5mm
- DC Resistance Max: 0.22ohm
- Inductance Tolerance: ± 10%
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 7mm
- External Length / Height: 5mm
- External Width: 7.8mm
- Lead Spacing: 3mm
- No. of Pins: 2Pins
- Resonant Frequency: 100kHz
