MULTICOMP PRO - MCNL453232-820K - Wirewound Inductor, 82 µH, 7 ohm, 8 MHz, 120 mA, 1812 [4532 Metric], MCNL45
- Inductance: 82µH
- Product Range: MCNL45 Series
- DC Current Rating: 120mA
- High Frequency Inductor Case: 1812 [4532 Metric]
- Inductor Construction: Wirewound
- DC Resistance Max: 7ohm
- Inductance Tolerance: ± 10%
- Self Resonant Frequency Min: 8MHz
- SVHC: No SVHC (15-Jan-2019)
- External Depth: 3.2mm
- External Length / Height: 4.5mm
- External Width: 3.2mm
- Inductor Case Style: 1812 [4532 Metric]
