MULTICOMP PRO - MCMR35V226M5X7 - Electrolytic Capacitor, 22 µF, 35 V, ± 20%, Radial Leaded, 1000 hours @ 85°C, Polar
- Capacitance: 22µF
- Voltage Rating: 35V
- Product Range: MCMR Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 5mm
- Lead Spacing: 2mm
- Height: 7mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Lifetime @ Temperature: 1000 hours @ 85°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- ESR Frequency: 120Hz
- External Length / Height: 7mm
- Frequency Tolerance: 120Hz
- Lead Diameter: 0.45mm
- Leakage Current: 4.7µA
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 1000h
- Outer Diameter: 5mm
- Ripple Current AC: 47mA
- Ripple Current Temperature: 85°C
- Tolerance +: 20%
- Tolerance Temperature: 20°C
- Voltage Rating V DC: 35V
