Description
MULTICOMP PRO - MC36200 - Resettable Fuse, PPTC, MC36, 60 VDC, 1.85 A, 3.7 A, 12.6 s, Round
- Thermistor Mounting: Through Hole
- Product Range: MC36 Series
- Holding Current: 1.85A
- Tripping Current: 3.7A
- Voltage Rating: 60VDC
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Carrying Current Max: 40A
- Current Max: 40A
- External Depth: 3.1mm
- External Length / Height: 22.9mm
- External Width: 17.8mm
- Height: 22.9mm
- Holding Current Max Ih: 1.85A
- Initial Resistance Max: 0.19ohm
- Initial Resistance Min: 0.08ohm
- Lead Diameter: 0.81mm
- Lead Length: 7.6mm
- Lead Spacing: 10.2mm
- Operating Voltage: 60VDC
- Operating Voltage Max: 60VDC
- PTC Fuse Case Style: Radial Leaded
- Voltage: 60V
