MULTICOMP PRO - MC36191 - Resettable Fuse, PPTC, MC36, 60 VDC, 400 mA, 800 mA, 3.8 s, Round
- Thermistor Mounting: Through Hole
- Product Range: MC36 Series
- Holding Current: 400mA
- Tripping Current: 800mA
- Voltage Rating: 60VDC
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Carrying Current Max: 40A
- Current Max: 40A
- External Depth: 3.1mm
- External Length / Height: 13.5mm
- External Width: 7.6mm
- Height: 13.5mm
- Holding Current Max Ih: 0.4A
- Initial Resistance Max: 1.29ohm
- Initial Resistance Min: 0.55ohm
- Lead Diameter: 0.51mm
- Lead Length: 7.6mm
- Lead Spacing: 5.1mm
- Operating Voltage: 60VDC
- Operating Voltage Max: 60VDC
- PTC Fuse Case Style: Radial Leaded
- Voltage: 60V
