Description
MULTICOMP PRO - MC36185 - Resettable Fuse, PPTC, MC36, 90 VDC, 150 mA, 350 mA, 10 s, Round
- Thermistor Mounting: Through Hole
- Product Range: MC36 Series
- Holding Current: 150mA
- Tripping Current: 350mA
- Voltage Rating: 90VDC
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Carrying Current Max: 40A
- Current Max: 40A
- External Depth: 3.1mm
- External Length / Height: 12.7mm
- External Width: 7.4mm
- Height: 12.7mm
- Holding Current Max Ih: 0.15A
- Initial Resistance Max: 7ohm
- Initial Resistance Min: 2.4ohm
- Lead Diameter: 0.51mm
- Lead Length: 7.6mm
- Lead Spacing: 5.1mm
- Operating Voltage: 90VDC
- Operating Voltage Max: 90VDC
- PTC Fuse Case Style: Radial Leaded
- Voltage: 90V
