Description
MULTICOMP PRO - MC000009 - Wire-To-Board Terminal Block, Wire to Board, 2.54 mm, 2 Ways, 26 AWG, 20 AWG, -99 mm², Push In
- Pitch Spacing: 2.54mm
- No. of Positions: 2Ways
- Wire Size AWG Min: 26AWG
- Wire Size AWG Max: 20AWG
- Conductor Area CSA: -99mm²
- Wire Connection Method: Push In
- Rated Current: 6A
- Rated Voltage: 150V
- Block Orientation: Through Hole Right Angle
- Product Range: MX Series
- SVHC: No SVHC (15-Jan-2019)
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, PCB
- Contact Material: Brass
- Contact Plating: Tin Plated Contacts
