Description
LITTELFUSE - LVR016K - Resettable Fuse, PPTC, PolySwitch LVR, 240 VAC, 160 mA, 370 mA, 15 s, Round
- Thermistor Mounting: Through Hole
- Product Range: PolySwitch LVR Series
- Holding Current: 160mA
- Tripping Current: 370mA
- Voltage Rating: 240VAC
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jun-2015)
- Approval Bodies: CSA, TUV
- Approval Category: UL Recognised
- Carrying Current Max: 2A
- External Depth: 3.8mm
- External Length / Height: 13.8mm
- External Width: 9.9mm
- Height: 13.8mm
- Holding Current Max Ih: 0.16A
- Initial Resistance Max: 4.1ohm
- Initial Resistance Min: 2.5ohm
- Lead Length: 7.6mm
- Lead Spacing: 5.8mm
- Operating Voltage: 240V
- PTC Fuse Case Style: Radial Leaded
- Response Time: 15s
- Thermistor Type: PTC Resettable Fuse
