Description
MEAN WELL - LPC-35-700 - LED Driver, ITE, 33.6 W, 48 V, 700 mA, Constant Current, 90 V
- Output Power Max: 33.6W
- Output Voltage Max: 48V
- Output Current: 700mA
- LED Driver Mode: Constant Current
- Input Voltage Min: 90V
- Input Voltage Max: 264V
- Product Range: LPC-35 Series
- SVHC: No SVHC (12-Jan-2017)
- Approval Bodies: CE
- Current Rating: 700mA
- Depth: 30mm
- Dimming Control Type: PWM
- Efficiency: 85%
- Height: 30mm
- IP Rating: IP67
- Length: 148mm
- No. of Channels: 1Channels
- No. of Outputs: 1Outputs
- Operating Temperature Max: 75°C
- Operating Temperature Min: -30°C
- Operating Temperature Range: -30°C to +75°C
- Output Power: 33.6W
- Output Voltage Min: 9V
- Power Supply Mounting: Chassis
- Power Supply Output Type: Adjustable, Fixed
- Power Supply Type: External Power Supply
- Supply Voltage: 230V
- Supply Voltage AC Max: 264V
- Supply Voltage AC Min: 90V
- Termination Style: Flying Leads
- Width: 40mm
