Description
- No. of Outputs: 1 Output
- Output Power Max: 8W
- Output Voltage - Output 1: 24V
- Output Current - Output 1: 335mA
- Output Voltage - Output 2: -
- Output Current - Output 2: -
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: JWE08 Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: DIP
- DC / DC Converter Mounting: Through Hole
- Width: 13.7mm
- Height: 8mm
- Depth: 23.8mm
- SVHC: No SVHC (15-Jan-2018)
- Approvals & Standards: IEC, UL
