JVN1AF-24V-F Relay, SPST-NO, 125VAC, 30Vdc, 16A Panasonic

PANASONICSKU: JVN1AF-24V-F Order code: 2095682

Price:
Sale price€10,28

Tax included Shipping calculated at checkout

Stock:
In stock (76 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - JVN1AF-24V-F - General Purpose Relay, JV-N Series, Power, Non Latching, SPST-NO, 24 VDC, 16 A

  • Contact Configuration: SPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 16A
  • Product Range: JV-N Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 125VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: 30VDC
  • Contact Material: Silver Tin Oxide
  • Coil Resistance: 2.88kohm
  • SVHC: No SVHC (07-Jul-2017)
  • Coil Current: 8.3mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 16A
  • Contact Voltage AC Nom: 125V
  • Contact Voltage DC Nom: 30V
  • External Depth: 22mm
  • External Height: 10.5mm
  • External Width: 16mm
  • Nom Operating Power: 200mW
  • Relay Type: Power
